This is something that I had wanted to do for a very long time. There are several methods for making your own PCB. Out of them
photolithography will probably give you the best results. However, toner transfer is one of the easiest and cheapest.
For my first toner transfer PCB, I used a
Kicad project (a transistor checker) from the great Japanese electronics magazine
Transistor Gijutsu (lit. transistor technology). I opened the project on Kicad with
pcbnew and printed the B.Cu (Backside copper) layer on a photo paper (the one in the picture is popular among Japanese hobbyists) using a laser printer. Reflecting back, I should have also printed the drill holes (just mark the "real drill" checkbox when you print the B.Cu layer) and add a copper-pour ground plane to save Ferric Chloride. Then, using an iron at the lowest possible temperature I transferred the footprint from the paper to a copper board. You have to be patient here (it took me 12 minutes) and apply enough pressure.
Next, put the board in hot water and remove the paper slowly with your fingers. Don't worry about the ink, it won't come off from the copper plate.
Clean deeply using a multipurpose or window cleaner.
Check the tracks carefully. If you notice that some tracks are not completely black cover them with a water-resistant pen. In this case I used a very strong pen especially made for PCBs. However, I would recommend using a normal one because this one was too strong and it was hard to remove it later.
You can easily cut your copper plate with a P-cutter tool.
Next put some Ferric Chloride into a zip bag together with your board, and swing it slowly inside a bucket with hot water (makes the reaction faster). Make sure you always wear rubber gloves and goggles when you handle Ferric Chloride because it's a very dangerous material. You will see how the exposed copper is slowly consumed by the Ferric Chloride. Once the copper is gone take the board out of the bag. Don't leave it for too long or the Ferric Chloride will attack your tracks from both sides.
This is the result. Notice how the tracks are still covered with the ink from the laser printer which prevented the Ferric Chloride from reacting with the copper.
Now take that ink off with acetone or a nail polish remover.
Drill the holes with a hand drill. I am using Tamiya's fine pin vice with a 0.8mm bit from Proxon.
Next solder your components into the board. Here I'm using lead-free solder which requires higher temperatures than lead solder. If your components are fragile or you are not quick enough with your soldering iron use lead solder instead.
Once the board is soldered it's time for testing. A typical multimeter will emit a sound when it finds a short.
If you make a mistake such as connecting a component in the wrong way, you can use desoldering braid or wick. Make sure your soldering iron is at a high enough temperature. Check other
desoldering techniques here.
If you are unlucky like me, you may need to debug further your circuit. In my case, I simulated the circuit on
LTSpice and found out that there was a mistake in the footprint. I solved it by cutting a track with a normal cutter.
And there you go, the transistor checker board is now working!.
Finally, make sure that you neutralize the PH of the resulting liquid (copper chloride) with sodium carbonate to a value between 7.0 and 8.0 (use a PH testing paper). Then, solidify the solution with cement and dispose of it. Never put it down the drain because the residual copper ions left in the solution can damage your pipes and the environment.
